Stainless Steel Wire Mesh

Home Products Wire Mesh Stainless Steel Wire Mesh Stainless Steel Wire Mesh
Stainless Steel Wire MeshStainless Steel Wire MeshStainless Steel Wire MeshStainless Steel Wire Mesh

Stainless Steel Wire Mesh

  • Product Item:Wiremesh01
  • Material: Stainless Steel 302 304 304L 316 316L 904L
  • Weaving Method: Plain,Twill,Dutch,Dutch Twill,Reverse Dutch,Five Heddle Weave
  • Feature: Mesh uniformity,bright colors,anti-aging,corrosion resistance,flat surface,strong tension
  • Payment: TT,Paypal,Western Union
  • Category:Stainless Steel Wire Mesh
  • Inquiry Send Email

    Description

    We manufacture the satisfied quality and the complete range of stainless steel wire cloth,including stainless square mesh,stainless steel dutch weave wire mesh.Stainless steel is wearing-resisting,heat-resisting,acid-resisting and corrosion resisting,because of its characteristics,the mesh made of stainless steel is extensively used in mining,chemical industry,food industry and pharmaceutical industry.

    Weave Method

    Plain weave: This is the most commonly used weave.Each warp wire crosses alternately above and below each weft wire. Warp and weft wires generally have the same diameter.

    Twill weave:Each weft wire passes alternately over two,and then under two successive warp wires and each warp wire passes alternately over two and under two successive weft wires.It is possible to be used to allow a heavier than standard wire diameter.We can supply the mesh from 30 mesh -500 mesh.

    Plain dutch weave:Woven as a plain weave,but with the warp wires of greater diameter than the weft wires.The weft wires are very close together so that a so-called zero-mesh structure is formed;while the warp wires are thicker and arranged wider apart.

    Twill dutch weave: “Twill” indicates the warp and weft wires pass alternately above two and below two wires.”Dutch” refers to the use of a heavier warp wire diameter in conjunction with a lighter weft wire diameter.This weave shows a combination of twill and dutch weave.

    Stainless Steel Wire Mesh Table

    Mesh/Inch Wire Diameter Aperture Open Area Weight(LB) /100 Square Foot
    Inch MM Inch MM
    1 x 1 .080 2.03 .920 23.37 84.6 41.1
    2 X 2 .063 1.60 .437 11.10 76.4 51.2
    3 X 3 .054 1.37 .279 7.09 70.1 56.7
    4 X 4 .063 1.60 .187 4.75 56.0 104.8
    4 X 4 .047 1.19 .203 5.16 65.9 57.6
    5 X 5 .041 1.04 .159 4.04 63.2 54.9
    6 X 6 .035 .89 .132 3.35 62.7 48.1
    8 X 8 .028 .71 .097 2.46 60.2 41.1
    10 X 10 .025 .64 .075 1.91 56.3 41.2
    10 X 10 .020 .51 .080 2.03 64.0 26.1
    12 X 12 .023 .584 .060 1.52 51.8 42.2
    12 X 12 .020 .508 .063 1.60 57.2 31.6
    14 X 14 .023 .584 .048 1.22 45.2 49.8
    14 X 14 .020 .508 .051 1.30 51.0 37.2
    16 X 16 .018 .457 .0445 1.13 50.7 34.5
    18 X 18 .017 .432 .0386 .98 48.3 34.8
    20 X 20 .020 .508 .0300 .76 36.0 55.2
    20 X 20 .016 .406 .0340 .86 46.2 34.4
    24 X 24 .014 .356 .0277 .70 44.2 31.8
    30 X 30 .013 .330 .0203 .52 37.1 34.8
    30 X 30 .012 .305 .0213 .54 40.8 29.4
    30 X 30 .009 .229 .0243 .62 53.1 16.1
    35 X 35 .011 .279 .0176 .45 37.9 29.0
    40 X 40 .010 .254 .0150 .38 36.0 27.6
    50 X 50 .009 .229 .0110 .28 30.3 28.4
    50 X 50 .008 .203 .0120 .31 36.0 22.1
    60 X 60 .0075 .191 .0092 .23 30.5 23.7
    60 X 60 .007 .178 .0097 .25 33.9 20.4
    70 X 70 .0065 .165 .0078 .20 29.8 20.8
    80 X 80 .0065 .165 .0060 .15 23.0 23.2
    80 X 80 .0055 .140 .0070 .18 31.4 16.9
    90 X 90 .005 .127 .0061 .16 30.1 15.8
    100 X 100 .0045 .114 .0055 .14 30.3 14.2
    100 X 100 .004 .102 .0060 .15 36.0 11.0
    100 X 100 .0035 .089 .0065 .17 42.3 8.3
    110 X 110 .0040 .1016 .0051 .1295 30.7 12.4
    120 X 120 .0037 .0940 .0064 .1168 30.7 11.6
    150 X 150 .0026 .0660 .0041 .1041 37.4 7.1
    160 X 160 .0025 .0635 .0038 .0965 36.4 5.94
    180 X 180 .0023 .0584 .0033 .0838 34.7 6.7
    200 X 200 .0021 .0533 .0029 .0737 33.6 6.2
    250 X 250 .0016 .0406 .0024 .0610 36.0 4.4
    270 X 270 .0016 .0406 .0021 .0533 32.2 4.7
    300 X 300 .0051 .0381 .0018 .0457 29.7 3.04
    325 X 325 .0014 .0356 .0017 .0432 30.0 4.40
    400 X 400 .0010 .0254 .0015 .370 36.0 3.3
    500 X 500 .0010 .0254 .0010 .0254 25.0 3.8
    635 X 635 .0008 .0203 .0008 .0203 25.0 2.63

    Stainless Steel Plain Dutch Weave Wire Cloth

    Mesh count per inch
    Wire diameter in inch Absolute filter rating microns
    Nominal filter rating microns
    8 X 85 .014 ×.0126 300-320 310
    12 X 64 .024 ×.0165
    260-280 250
    14 X 88 .020 ×.013
    255-275 250
    20 X 150 .0098 ×.007
    155-185 120
    24 X 110 .015 ×.010
    115-128 110
    30 X 150 .009 ×.007
    90-105 90
    40 X 200 .007 ×.0055
    70-80 70
    50 X 250 .0055 ×.0045
    52-57 55
    80 X 400 .0049 ×.0028
    40-45 40

    Stainless Steel Twill Dutch Weave Wire Cloth

    Mesh count per inch Wire diameter in inch Absolute filter rating microns
    Nominal filter rating microns
    20 X 250 .0098×.0079
    100-118 100
    30 X 360 .0098 ×.0060
    95-105 90
    40 X 560 .0070 ×.0040
    75-83 65
    80 X 700 .0040 ×.0030
    35-38 35
    200 X 600 .0024 ×.0018
    28-32 30
    165 X 800 .0028 ×.0020
    25-29 25
    165 X 1400 .0028 ×.0016
    16-18 15
    200 X 1400 .0028 ×.0016
    12-14 10
    250 X 1400 .0022 ×.0016
    11-13 9
    325 X 2300 .0015 ×.0010
    8-9 5
    500 X 3600 .0010 x.0006
    2-3 1

    Tags: Stainless steel wire mesh,stainless wire cloth,plain dutch weave wire mesh,twill dutch weave wire mesh
